| 加工定制 | 是 |
|---|---|
| 货号 | 6027P1.6 |
| 种类 | 传声器(咪头) |
| 类型 | 驻极体传声器 |
| 材质 | 铜 |
| 规格尺寸 | 6.0*2.7（mm） |
| 声道数 | 多声道 |
| 灵敏度 | -36~-60dB |
| 频率响应 | 50~20KHz |
| 输出阻抗 | 2.2KΩ |
| 主要下游平台 | 速卖通,亚马逊,wish,ebay,LAZADA,独立站 |
| 主要销售地区 | 欧洲,北美,南美,东南亚,东北亚,中东,非洲 |
| 是否跨境货源 | 是 |
| 品牌 | 领音者 |
| 型号 | FO6027P2.8-423-C1033 |
承認書 SPECIFICATION FOR APPROVAL
东莞市音**电子有限公司 工厂地址：东莞市长安镇增田恒泰路4号2楼 TEL：400-1140041 FAX：+86-769-85643930 E-mail：voicelerder@126.com
| ||||||||||||||||||||||||
1. Electrical characteristic: | |
directivity | Omnidirectiona1 |
Pb continuation Requirement | Lead free |
Charging type | Back Plate |
Sensitivity | 42 + 3dB（0dB=1V/Pa,1KHz） |
Output impedance | Low impedance |
Standard operating voltage | 2V |
Operating voltage range | 1V-1OV |
Current consumption | less than 500μA |
Voltage deduction characteristic | Within 3dB at 1.5V |
S/N Ratio | More than 60dB（SPL=1Pa, 1KHz, A-weighting） |
2.Frequency Response and Schematic Diagram 2.1 Typica1 Frequency Response Curve： 2.2 Schematic Diagram | |
3.Mechanical characteristics: 3.1 Weight:Less than 0.3g 3.2 Dimension: Unit: mm
4.Installation characteristics 4.1Recommend reflow profile
|
5.0 PACKING SKETCH MAP
|
6.Test **p drawing 6.1 Standard Frequency Response Test
Anechoic room
6.2 S/NS/N Ratio
Anechoic room
|
7.Reliability test | |||
Item | Test condition | evaluation | |
1 | High temperature Test | The part shall be capable of with- standing a storage temperature of +70℃ for 200 hours. | After the test the ECM unit shall meet the requirement of no more than ±3dB variation from initial sensitivity after 2 hours recovering. |
2 | Low temperature Test | The part shall be capable of with- standing a storage temperature of -20℃ for 200 hours. | |
3 | Temperature cycle test | The part shall be subjected to 5 cycle.One cycle shall consist of ﹝+70℃,30min→Room temp(+20℃), 10min→-20℃30min→Room temp(+20℃), 10min〕 | |
4 | Humidity Test | The part shall be capable of with- standing a storage of humidity of 90～95% at the +40℃ for 200 hours. | |
5 | Drop Test | The microphone unit without package must be subjected to each 3 drops at three axises from the height of 1 meter to 20 mm thick hardwood board. | |
6 | Vibration Test | The microphone unit must be subjected to each 2 hours vibrations at three axises 2mm dynamic range,10～50Hz/minute. | |
7 | Soldering Heat Resistance | Soldering iron of +330±5℃ should be placed on the terminal for 2±0.5 seconds. | |
8.drawing
| |||
产品简介 |
咪头，又称为咪芯 MIC 咪胆 器 拾音器 送话器 话筒 麦克风 等 从工作原理上有分为：碳晶粒咪头 电磁式咪头 电容式咪头 驻极体电容式咪头 压电晶体式咪头 压电陶瓷式咪头 二氧化硅式咪头 SMD贴片式咪头 硅咪 等 |
我们的优势 |
|
产品展示 |
|
产品应用 |
|
