德国威琅 wieland 分配器 RST20I5B 2P1 F VG SW 96.050.1153.1

种类	FFC/FPC
工作频率	低频
应用范围	PCB
形状	条形
线长	2（mm）
制作工艺	冷压
特性	防潮
接触件材质	2
绝缘体材质	2
芯数	2
针数	2
订货号	2
最小包装数	2
额定电流	20 A
额定电压	400 V
接口类型	1394
适用范围	电工电气
品牌	德国威琅 wieland
型号	96.050.1153.1
加工定制	否
物料编号	2

分配器 RST20I5B 2P1 F VG SW

物料号????96.050.1153.1

RST RST20i5紧凑型分配器，5极，1路输入，2路输出，带安装选项，250/400V，20A，编码颜色：黑色

????

总则 额定电流 20 A 额定电压 400 V 额定脉冲电压 4 kV 污染等级 3 机械编码 是 可内锁 是 编码颜色/触点载体 黑色 ???? 型号 输入数 1 输出数 2 紧固件类型 是 IP防护等级 IP66/68 (3m;2h) /IP69 分配器类型 组合分配端子 ???? 材料 外壳 聚酰胺 无卤素 是 接触材料 CuZn 绝缘部件连续温度 100 °C 表面处理 镀银 ???? 尺寸 长度 160 mm 宽度 104 mm 高度 56,5 mm ???? Classification ECLASS 8.1 27440603: 用于即插式建筑安装的紧凑型配电箱 ETIM 5.0 EC002567: 用于即插式建筑安装的紧凑型配电箱 ETIM 4.0 EC002567: 用于即插式建筑安装的紧凑型配电箱
