- 品牌：万尊
- 型号：SH-10060
- 类型：动铁单元
- 用途：监听
- 声道数：双声道立体声
- 磁路结构：双磁路式
- 组成方式：同轴复合
- 外形：矩形
- 振膜材料：非纸质
- 频率特性：高音扬声器
- 阻抗：120 ohm
- 大小：5.08*2.75*2.58
- 灵敏度：100
- 失真：＜5
- 频响：3-1000
苏州万尊电子科技有限公司,动铁单元,动铁受话器生产商,广泛适用于助听器,音乐耳机等.
厂家直销动铁单元,动铁喇叭,动铁受话器,助听器喇叭,微型喇叭
系列:HK,SH,SZ,GZ,CD.........
提供阻抗:4 ohm,10 ohm,22 ohm,35 ohm,60 ohm,120 ohm,360 ohm,515 ohm.........
SZ Series | SH Series | |
Outline Dimension(mm) | 5.18*3.60*3.00 | 5.08*2.75*2.58 |
Sensitivity @1000Hz(dB) | 102.5 | 100 |
Available Impedance Range(ohm) | 3-1000 | 3-1000 |
THD @ Nominal Drive(%) | ＜5% | ＜5% |
Maximun Output(dB) | ＞130 | ＞120 |
Available Impedance | 22,60,120 | 22,60,120 |
Typical Application | -Receiver for hearing aid instruments （ITE / CIC) -Tweeter/Wideband driver for headsets & headphones -Transducer for blue-tooth headsets | -Receiver for hearing aid instruments （IIC / CIC) -Tweeter driver for headsets & headphones -Transducer for blue-tooth headsets |
Product Feature | -Perfect package size for multi-driver headset applications -Outstanding efficiency -Extended bandwidth -Substantial maximum output -Magnetic-radiation shielded -Optimized mechanical shock resistance -Water resisted | -Perfect package size for ITE,CIC,IIC applications -outstanding efficiency -Substantial maximum output -Magnetic-radiation shielded -Optimized mechanical shock resistance -Water resisted |
